ONV GWS‑DP120‑48 120 W DIN Rail Power Supply, DC 48 V 2.5 A, AC 90–264 V Input, TS‑35 Mountable, Industrial Protection

Model: GWS-DP120-48

SKU: 5509

Category: Power Supply (PSU)

Brand: ONV

Warranty: Reliable Quality, Backed by a 1 Year Warranty

AED 199.00

Inclusive of VAT

Sold By: PC7

Availability: In Stock

Condition: New

Delivery To: Columbus

Delivered by: Delivery not available in United States



  • Description
  • Product Reviews
  • Specifications

ONV GWS‑DP120‑48 120 W DIN Rail Power Supply, DC 48 V 2.5 A, AC 90–264 V Input, TS‑35 Mountable, Industrial Protection

The ONV GWS‑DP120‑48 is a rugged industrial-grade 120 W DIN rail power supply delivering 48 V DC at 2.5 A, conforming to German standards and EN61000‑3‑2 harmonic emission limits. Supports universal AC input (90–264 VAC), high efficiency over 90%, wide ambient operation from −40 °C to +70 °C, and full protection against short circuit, over-voltage, and over-current. With a slim metal housing for enhanced heat dissipation, constant-current mode, and 100% burn-in testing, it provides reliable performance in automation, control systems, semiconductor fabrication, and factory environments.

Customer Reviews Write a Review

No reviews yet for this product.

Add a Review

General

Weight: 0.50 kg
Dimensions: 20x10x5 cm

Specifications

  1. Brand: ONV
  2. Model / MPN: GWS-DP120-48
  3. Output Voltage: 48.00–48.2 V DC (nominal)
  4. Rated Output Current: 2.5 A
  5. Rated Output Power: 120 W
  6. Peak Output Power: Up to 180 W for 10 seconds (at 220 VAC)
  7. Ripple & Noise: ≤100 mV peak-to-peak (20 MHz bandwidth)
  8. Voltage Regulation: ±1% output, ±0.5% line regulation, ±1% load regulation
  9. Output Hold-up Time: >20 ms @ 115 VAC, >50 ms @ 230 VAC (full load)
  10. Start-up Time: <2 seconds at 100% load
  11. Input Voltage Range: 90–264 VAC, 47–63 Hz
  12. Efficiency: >90% @ 115 VAC, >91% @ 230 VAC
  13. Power Factor: >0.99 @ 115 VAC, >0.93 @ 230 VAC
  14. Protections: Over-power, over-voltage, short circuit (auto-recovery)
  15. Operating Temperature: -40 °C to +70 °C
  16. Storage Temperature: -40 °C to +85 °C
  17. Operating Humidity: 5–95% RH non-condensing
  18. Cooling: Convection cooled, metal housing
  19. Mounting: TS-35/7.5 or TS-35/15 DIN rail compatible
  20. Dimensions (W×D×H): 134 × 124 × 41 mm
  21. Weight: Approx. 580 g
  22. Certifications: EMC standards per EN61000-3-2, CE, RoHS compliant
  23. Product Type: Industrial DIN Rail AC/DC Power Supply 120 W
