{"Chipset\tAMD X870":"CPU\tSupports AMD Ryzen\u2122 9000\/ 8000\/ 7000 Series Desktop Processors","Socket AM5":"Memory\t4x DDR5 UDIMM, Maximum Memory Capacity 256GB","Ryzen\u2122 9000 Series Processors max. overclocking frequency":"\u2022 1DPC 1R Max speed up to 8400+ MT\/s","\u2022 1DPC 2R Max speed up to 6400+ MT\/s":"\u2022 2DPC 1R Max speed up to 6400+ MT\/s","\u2022 2DPC 2R Max speed up to 4800+ MT\/s":"Supports AMD POR Speed and JEDEC Speed","Supports Memory Overclocking and AMD EXPO\u2122":"Supports Dual-Channel mode","Supports Non-ECC, Un-buffered memory":"Supports CUDIMM, Clock Driver bypass mode only*","* CUDIMM support and POR boot frequency may vary by CPU series, with manual overclocking available after boot. Certain CPUs may fail to boot, but future BIOS updates will improve compatibility.":"\u2022 The DIMM slots on this motherboard have double-sided latches.","\u2022 Memory compatibility and supported speeds can vary depending on the CPU and memory configuration. For detailed information, please refer to the Memory Compatibility List available on the product\u2019s Support page or visit https":"Onboard Graphics\t1x HDMI\u2122","Support HDMI\u2122 2.1 FRL, maximum resolution of 8K 60Hz*":"2x Type-C DisplayPort","USB4\u00ae port, supporting DisplayPort 1.4 with HBR3 over USB Type-C, maximum resolution of 4K 60Hz*":"*Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.","Slot\t3x PCI-E x16 slot":"PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU)","PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)":"PCI_E3 Gen PCIe 4.0 supports up to x4 (From Chipset)","PCI_E1 slot":"\u2022 Supports PCIe 5.0 x16 (For Ryzen\u2122 9000\/ 7000 Series processors)","\u2022 Supports PCIe 4.0 x8 (For Ryzen\u2122 8700\/ 8600\/ 8400 Series processors)":"\u2022 Supports PCIe 4.0 x4 (For Ryzen\u2122 8500\/ 8300 Series processor)","*PCI_E3 slot will run at x2 speed when installing device in the M2_3 slot. You can switch PCI_E3 slot to x4 in the BIOS, but this will disable the M2_3 slot":"Audio\tRealtek\u00ae ALC4080 Codec","7.1-Channel USB High Performance Audio":"Supports up to 32-bit\/384kHz playback on front panel","Supports S\/PDIF output":"Storage\t4x M.2","M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 22110\/2280 devices":"M.2_2 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280\/2260 devices","M.2_3 Source (From Chipset) supports up to PCIe 4.0 x2 , supports 2280\/2260 devices":"M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280\/2260 devices","4x SATA 6G":"M2_1 & M2_2 slots","\u2022 Supports up to PCIe 5.0 x4 (For Ryzen\u2122 9000\/ 7000 Series processors)":"\u2022 Supports up to PCIe 4.0 x4 (For Ryzen\u2122 8000 Series processors)","* The M2_2 slot will be unavailable when using Ryzen\u2122 8500\/ 8300 Series processors.":"** USB 40Gbps Type-C ports on the back panel and M2_2 slot share PCIe 5.0 x4 bandwidth. Both run at PCIe 5.0 x2 when a device is installed in the M2_2 slot. You can switch M2_2 to PCIe 5.0 x4 in the BIOS, but this will disable the USB 40Gbps Type-C ports","*** PCI_E3 slot will run at x2 speed when installing device in the M2_3 slot. You can switch PCI_E3 slot to x4 in the BIOS, but this will disable the M2_3 slot.":"**** Please refer to the manual for M.2 SSD heatsink restrictions","Multi-GPU\tAMD MULTI-GPU Support":"RAID\tSupports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices","USB\t4x USB 2.0 (Rear)":"4x USB 2.0 (Front)","3x USB 5Gbps Type A (Rear)":"4x USB 5Gbps Type A (Front)","2x USB 10Gbps Type A (Rear)":"1x USB 10Gbps Type C (Rear)","1x USB 20Gbps Type C (Front)":"2x USB 40Gbps Type C (Rear)","LAN\tRealtek\u00ae 8126-CG 5G LAN":"Internal IO\t1x Power Connector(ATX_PWR)","2x Power Connector(CPU_PWR)":"1x Power Connector(PCIE_PWR 8pin)","1x CPU Fan":"1x Combo Fan (Pump_Sys Fan)","6x System Fan":"1x EZ Conn-header (JAF_2)","2x Front Panel (JFP)":"1x Chassis Intrusion (JCI)","1x Front Audio (JAUD)":"3x Addressable V2 RGB LED connector (JARGB_V2)","1x RGB LED connector(JRGB)":"1x TPM pin header(Support TPM 2.0)","4x USB 2.0 ports":"4x USB 5Gbps Type A ports","1x USB 20Gbps Type C ports":"WIRELESS LAN & BLUETOOTH\tWi-Fi 7","The Wireless module is pre-installed in the M.2 (Key-E) slot":"Supports MU-MIMO TX\/RX, 2.4GHz\/ 5GHz\/ 6GHz* (320MHz) up to 5.8Gbps","Supports 802.11 a\/ b\/ g\/ n\/ ac\/ ax\/ be":"Supports Bluetooth\u00ae 5.4**, MLO, 4KQAM","* 6GHz band support may depend on every country\u2019s regulations and Wi-Fi 7 will be ready in Windows 11 version 24H2.":"** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor\u2019s website for details. Bluetooth 5.4 will be ready in Windows 11 version 24H2.","LED FEATURE\t4x EZ Debug LED":"1x EZ Digit Debug LED"}
